Grid Connected Inverter MATLAB Simulation

Most automotive electrification systems focus on grid-to-vehicle power transfer, where grid-connected chargers deliver high-voltage DC power to vehicles. However, the reverse capability—vehicle-to-grid (V2G) technology—opens up exciting possibilities.

This page presents a MATLAB Simulink model of an inverter synchronized to the utility grid’s 60 Hz fundamental frequency. This bidirectional power flow technology enables several practical applications: emergency backup power for homes, alternative energy sourcing through vehicle batteries, and improved grid stability through power factor correction.

Single Phase VFD Controller

Electric motors serve as the backbone of industrial automation, driving conveyor systems, pumps, fans, and countless process equipment. Traditional fixed-speed operation often proves inadequate for applications requiring variable output, making variable frequency drives (VFDs) essential for optimal performance.

VFDs control motor operation by varying the frequency and voltage supplied to the motor, enabling precise speed and torque modulation that matches real-time load demands. Beyond improved process control, VFDs significantly reduce mechanical stress through soft-start capabilities and controlled ramping, minimizing wear on motor bearings, couplings, and driven equipment.

Power Protection and Supply Circuit Design

Protecting circuits from transients and electrical over stress (EOS) represents a core responsibility in electrical engineering practice. EOS events originate from diverse sources including reverse polarity connections, short circuits, lightning-induced surges, electrostatic discharge, and various other electrical anomalies that can compromise circuit integrity.

The following design showcases a galvanically isolated power supply incorporating multi-layered protection strategies:

→ Reverse Voltage

→ Over Voltage/Current: Including ESD and Transients
